5.3 Modes of Operation

It is wise to label the USB / floppy to identify the way you plan to use Active@ KillDisk for Hard Drives.

DOS Interactive Mode and Command Line Mode are similar in that you can control what happens after the utility has started. In Autoexecute Mode, however, Active@ KillDisk for Hard Drives will start immediately upon completion of the bootstrap startup (depending on the automatic settings).

5.3.1 DOS Interactive Mode

This section describes how to use the DOS Interactive screens. For "hands-off" operation, see 3.3.3 Autoexecute Mode.

The steps for erasing data and wiping data are similar. Follow steps 1 through 13 and then click the link to complete either the erasing process or the wiping process.

If you are booting from a USB / floppy drive, check that the USB / floppy drive has boot priority in the BIOS settings of your computer.

If you are booting from a CD, check that the CD drive has boot priority in the BIOS settings of your computer.

Here are the steps for interactive operation:
  1. With the PC power off, insert either the Active@ KillDisk bootable USB / floppy disk into drive A: or the Active@ KillDisk bootable CD into your CD-ROM drive.
  2. Start the PC by turning on the power. The screen will display the Microsoft DOS prompt.
  3. At the DOS prompt, run Active@ KillDisk for Hard Drives by typing: KILLDISK.EXE

    The Detected Physical Devices screen appears.

    Detected Physical Devices. Screenshot

    All system physical devices and logical partitions are displayed in a list.
  4. Change the position of the cursor in the list using the keyboard [Down] and [Up] arrow keys. A list of commands is displayed below the device list.

    Hard drive devices are numbered by the system BIOS. A system with a single hard drive shows as number 0. Subsequent hard drive devices are numbered consecutively. For example the second device will be shown as Hard Disk 1.

    Select a device and read the detailed information about the device in the right pane. Below the device, select a logical partition. The information in the right pane changes. As well the list of commands changes.
  5. Be certain that the drive you are pointing to is the one that you want to erase or the one you want to wipe. If you choose to erase, all data will be permanently erased with no chance for recovery.

    To preview the sectors in a device, press [Ctrl + S]. The Preview Sector screen appears.

    Preview Sector

    Erase hard disk. Preview Sector. Screenshot
  6. Press [Tab] to switch to the right panel.
  7. To see items in the list, use [Page Down], [Page Up] or the up or down arrow keys.
  8. To open a folder, move the cursor to the folder and press [Enter]. KillDisk scans the MFT records for this folder. The files in the folder appear in the right panel.

    Existing file names and folder names appear in white colour and deleted file names and folder names appear in gray colour. If you are wiping data from unoccupied areas, the gray-coloured file names are removed after the wiping process completes. You may use Files Preview to inspect the work done by the wiping process. After wiping, the data in these areas and the place these files hold in the root records or MFT records are gone.
  9. Press [Esc] to close this screen and return to Detected Physical Devices.

At this point, link to the steps to either erase the data or wipe the data.
